Forged flanges

Precision forged. Machined for critical service.

DIMENSIONAL BASIS

ASME B16.5

Specify the pressure class your project requires. Seric confirms qualified combinations against each enquiry.

ASME B16.5 scope: NPS ½–24 for Classes 150, 300, 400, 600, 900 and 1500; Class 2500 extends only to NPS 12. These are standard designations, not a statement of Seric production capacity. ASME scope reference ↗

Planned portfolio range: ½″–24″. Send your required class, facing, bore and material. Each combination is subject to technical confirmation.

Forged flanges

Weld neck flanges ↗

Flanges with a welding neck. Specify the pipe schedule or bore alongside size, class and facing.

View product requirementsForged flanges

Slip-on flanges ↗

Slip-on connections defined by size, class, facing and material. Include the mating pipe dimensions.

View product requirementsForged flanges

Blind flanges ↗

Closures for flanged connections. Specify pressure class, facing, material and any special drawing requirements.

View product requirementsForged flanges

Socket weld flanges ↗

Socket-weld connections subject to confirmation of the requested size, class and material combination.

View product requirementsForged flanges

Threaded flanges ↗

Threaded connections specified against the project requirement. Include thread form, size, class and facing.

View product requirementsForged flanges

Lap joint flanges ↗

Flanges used with compatible stub ends. Include the stub-end dimensions and material requirements.

View product requirements
FLANGE MANUFACTURING ROUTE

From raw material
to marked component.

Nine illustrative manufacturing scenes, read left to right by row: raw material, cutting, heating, forging and ring rolling, heat treatment, CNC machining, drilling, inspection and marking.
Flange manufacturing process · AI-generated illustration, not photographs of the SERIC facility. Read left to right, from the top row. Select the image to enlarge.
  1. 01Raw material
  2. 02Cutting
  3. 03Heating
  4. 04Forging / ring rolling
  5. 05Heat treatment
  6. 06CNC machining
  7. 07Drilling
  8. 08Inspection
  9. 09Marking

Applicable operations depend on the material, product and qualified manufacturing route.

Forged material specifications

Material references for forged flanges
Material familySpecificationGrades / request details
Carbon / low-temperature carbon steelASTM A105 / ASTM A350A105 / specified A350 grade
Alloy steelASTM A182F11 · F22 · F91
Stainless steelASTM A182F304 / F304L · F316 / F316L
Duplex / super duplexASTM A182F51 · F53 · F55
Nickel alloysASTM B564Specify the alloy / UNS designation, e.g. Alloy 625

Confirm the exact grade, class, facing and bore with your enquiry.
